功能点Feature and functions
●操作简单，电脑自动控制系统，中文屏幕液晶显示，洗涤过程一目了然，洗涤程序随意选定。
●蒸汽加热及电加热可选用，排水采用下排水，可用软管引至地沟，保持室内清洁。
●加料箱采用热水冲料解决了碱粉不易溶于冷水，结垢的弊病。
●脱水安控制功能，当不平衡力过时自动停止并报警。
●水位自动控制系统、电脑程序控制，兼带手动4种水位设定可选，水温自动控制任选。
●安门锁和控制联动装置，具有保护功能（当设备运行时能拒绝开门等误操作）。
●机体和底座采用焊接结构，机器内部、外部结构采用抗腐能力强的环氧树脂漆，机体外部面板采用不锈钢板制成。
●洗涤室、洗涤脱水桶卧式安装、热喷锌外缸、防腐蚀；内胆采用质不锈钢材料焊接而成。主要零部件采用进口或国内质；如：变频器采用LG，主轴承采用美国铁姆肯。
●采用悬浮减震结构与变频驱动，加速平稳，有效化解机器的振动，脱时振幅公分1.5MM，脱水力达到270KG，脱水后衣物含水量于标准，无须固定。
●变频器采用LG变频器，可根据需要任意设定转速
●The wash room, the wash escape the bucket horizontal type install; In the gallbladder uses the high quality stainless steel material welding to become. The essential spare part uses the import or the domestic high quality brand; For example: The frequency changer uses LG, the main bearing uses American iron to be willing.
●Uses entire aerosol absorption of shock structure and the frequency conversion actuation, the acceleration is steady, melts machine's vibration effectively, high speed oscillation amplitude centimeter 1.5MM, the dehydrated strength achieves 270KG, after the dehydration, the clothing water content surpasses the national standards, does not need the ground.
●Frequency changer uses the LG frequency changer, may according to need to establish the rotational speed willfully.
●Simplicity of operator, the computer completely automatic control system, Chinese large screen liquid crystal display that the wash process is clear, the wash procedure designated at will.
●Steam heating and the electric heating may select, under draining water uses drains water, the available hose directs to the trench, maintains indoor clean.
●Added the feed box to use the hot water to flush the material to solve the alkali powder not to be easy to dissolve in cold water, scaling disease.
●Dehydration safety control function, when the balance force is not over sized the automatic stopping and reports to the police.
●Height water level automatic control system, the entire computer programmed control, the concurrently belt manual 4kind of water level hypothesis may elect, the water temperature automatic control is optional.
●Security door lock and the control lineage , has the protection function, (when equipment moves can refuse to open the door and so on immoderate.
●Organism and the foundation use the welding structure, the machine interior, the exterior all structures use the anti spoiled ability strong epoxy resin varnish, the organism exterior kneading board use the stainless steel plate to make.
●操作简单，电脑自动控制系统，中文屏幕液晶显示，洗涤过程一目了然，洗涤程序随意选定。
●蒸汽加热及电加热可选用，排水采用下排水，可用软管引至地沟，保持室内清洁。
●加料箱采用热水冲料解决了碱粉不易溶于冷水，结垢的弊病。
●脱水安控制功能，当不平衡力过时自动停止并报警。
●水位自动控制系统、电脑程序控制，兼带手动4种水位设定可选，水温自动控制任选。
●安门锁和控制联动装置，具有保护功能（当设备运行时能拒绝开门等误操作）。
●机体和底座采用焊接结构，机器内部、外部结构采用抗腐能力强的环氧树脂漆，机体外部面板采用不锈钢板制成。
●洗涤室、洗涤脱水桶卧式安装、热喷锌外缸、防腐蚀；内胆采用质不锈钢材料焊接而成。主要零部件采用进口或国内质；如：变频器采用LG，主轴承采用美国铁姆肯。
●采用悬浮减震结构与变频驱动，加速平稳，有效化解机器的振动，脱时振幅公分1.5MM，脱水力达到270KG，脱水后衣物含水量于标准，无须固定。
●变频器采用LG变频器，可根据需要任意设定转速
●The wash room, the wash escape the bucket horizontal type install; In the gallbladder uses the high quality stainless steel material welding to become. The essential spare part uses the import or the domestic high quality brand; For example: The frequency changer uses LG, the main bearing uses American iron to be willing.
●Uses entire aerosol absorption of shock structure and the frequency conversion actuation, the acceleration is steady, melts machine's vibration effectively, high speed oscillation amplitude centimeter 1.5MM, the dehydrated strength achieves 270KG, after the dehydration, the clothing water content surpasses the national standards, does not need the ground.
●Frequency changer uses the LG frequency changer, may according to need to establish the rotational speed willfully.
●Simplicity of operator, the computer completely automatic control system, Chinese large screen liquid crystal display that the wash process is clear, the wash procedure designated at will.
●Steam heating and the electric heating may select, under draining water uses drains water, the available hose directs to the trench, maintains indoor clean.
●Added the feed box to use the hot water to flush the material to solve the alkali powder not to be easy to dissolve in cold water, scaling disease.
●Dehydration safety control function, when the balance force is not over sized the automatic stopping and reports to the police.
●Height water level automatic control system, the entire computer programmed control, the concurrently belt manual 4kind of water level hypothesis may elect, the water temperature automatic control is optional.
●Security door lock and the control lineage , has the protection function, (when equipment moves can refuse to open the door and so on immoderate.
●Organism and the foundation use the welding structure, the machine interior, the exterior all structures use the anti spoiled ability strong epoxy resin varnish, the organism exterior kneading board use the stainless steel plate to make.
ySX系列自动洗脱机技术参数 Technical parameters
|
型号 model 项目 item |
QXSQ-100 | QXSQ-70 | QXSQ-50 | QXSQ-30 | |
| 洗涤额定容量（ kg） | Washing rated capacity | 100 | 70 | 50 | 30 |
| 转笼（mm） | Gxl cage gxl | 1200×820 | 1200×626 | 1070×610 | 900×500 |
| 洗衣转速（rpm） | Laundry speed | 32 | 34 | 36 | 36 |
| 脱脱水转速（rpm） |
High speed removal dehydration |
670 | 670 | 700 | 720 |
| 电机功率（KW） | Motor power | 7.5 | 7.5 | 5.5 | 4 |
| 蒸汽管通径（mm） | Drain pipe sizes | 25 | 25 | 25 | 20 |
| 冷热水管通径（mm） |
Hot and cold water pipes Path |
40 | 40 | 40 | 30 |
| 排水管通径（mm） | Drain pipe sizes | ø160 | ø140 | ø140 | ø140 |
| 耗水量 （kg/一洗二漂） | Tap water pressure | 1181 | 924 | 758 | 473 |
| 耗汽耗比 | The consumption f steamconsumption than/kg | 0.9 | 0.9 | 0.9 | 0.9 |
| 自来水压力（Mpa） | Tap water pressure | 0.2-0.3 | 0.2-0.3 | 0.2-0.3 | 0.2-0.3 |
| 蒸汽压力（Mpa） | Steam pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| 噪声（B） | Noised | ＞70 | ＞70 | ＞70 | ＞70 |
| 长×宽×（mm） | Dimension (width) | 1770×1860×2300 | 1770×1800×2300 | 1600×1500×1920 | 1400×1380×1760 |
| 整机重量（kg） | Machine weigh | 3200 | 2700 | 2500 | 1800 |
