功能点Feature and functions
●使用溶剂为烷烃碳氢溶剂D-60、D-80和D-F2000等。
●不锈钢结构,承重载主轴及结构设计,确保机器具有长久的寿命。
●两溶剂箱设计,方便各种洗涤需求。
●600转/分的甩干速度,节省了烘干时间和能源的消耗,同时避免过的甩干速度对档衣物产生损害。
●的单组串联式复合过滤系统设计,配合功率溶剂泵,能够处理敏感的衣物。
●使用KH-200A电脑控制,外观美观,操作简单。
●采用的真空防爆烘干系统,确保安可靠,缩短烘干时间。
●采用多点温度、压力自动保护装置技术,配备性能制冷回收系统,确保溶剂的回收率达95以上。
●电器控制元器件,确保机器长期无故障运行。
●简体门及其它清理门都有装有安自锁装置。
●殊设计的溶剂箱结构,防止水份进入干洗系统。
●The use of solvents for the paraffin hydrocarbon solvent D-60, D-80 and D-F2000, etc.
●Stainless steel structure, load-bearing spindle set and structural design, to ensure that the machines have a long life.
●Me design the two solvents to facilitate the demand for all kinds of washing.
●600 r/min dry the speed of drying time and saving energy consumption, while avoiding excessive speed on high end clothing Extractors harm.
●Unique series of single composite filter system design, with high-power solvent pump, capable of handling the most sensitive clothing.
●KH-200A using computer control, the appearance of beau-
tiful, easy to operate.
●Unique anti-vacuum drying system to ensure safe and reliable, to shorten the drying time.
●The use of multi point temperature, pressure automatic protection device technology, with high-performance refri-
gerant recovery system to ensure that the solvent recovery up to 95.
●The world famous brand electrical control components to ensure long-term trouble-free operation of the machine.
●Simplified clean-up doors and other doors are equipped with a safety locking device.
●Solvents specially designed box structure to prevent water entering the cleaning system.
●使用溶剂为烷烃碳氢溶剂D-60、D-80和D-F2000等。
●不锈钢结构,承重载主轴及结构设计,确保机器具有长久的寿命。
●两溶剂箱设计,方便各种洗涤需求。
●600转/分的甩干速度,节省了烘干时间和能源的消耗,同时避免过的甩干速度对档衣物产生损害。
●的单组串联式复合过滤系统设计,配合功率溶剂泵,能够处理敏感的衣物。
●使用KH-200A电脑控制,外观美观,操作简单。
●采用的真空防爆烘干系统,确保安可靠,缩短烘干时间。
●采用多点温度、压力自动保护装置技术,配备性能制冷回收系统,确保溶剂的回收率达95以上。
●电器控制元器件,确保机器长期无故障运行。
●简体门及其它清理门都有装有安自锁装置。
●殊设计的溶剂箱结构,防止水份进入干洗系统。
●The use of solvents for the paraffin hydrocarbon solvent D-60, D-80 and D-F2000, etc.
●Stainless steel structure, load-bearing spindle set and structural design, to ensure that the machines have a long life.
●Me design the two solvents to facilitate the demand for all kinds of washing.
●600 r/min dry the speed of drying time and saving energy consumption, while avoiding excessive speed on high end clothing Extractors harm.
●Unique series of single composite filter system design, with high-power solvent pump, capable of handling the most sensitive clothing.
●KH-200A using computer control, the appearance of beau-
tiful, easy to operate.
●Unique anti-vacuum drying system to ensure safe and reliable, to shorten the drying time.
●The use of multi point temperature, pressure automatic protection device technology, with high-performance refri-
gerant recovery system to ensure that the solvent recovery up to 95.
●The world famous brand electrical control components to ensure long-term trouble-free operation of the machine.
●Simplified clean-up doors and other doors are equipped with a safety locking device.
●Solvents specially designed box structure to prevent water entering the cleaning system.
型号 model 项目 item |
单位unit |
Y500FSQ 6 |
Y500FSQ 8 |
Y500FSQ 10 |
Y500FSQ 12 |
Y500FSQ 15 |
||
洗衣容量Loading weight | kg | 6-8 | 8-10 | 10-12 | 2-14 | 15-18 | ||
滚筒容积Basket Volume | L | 138 | 160 | 200 | 240 | 300 | ||
清洗转速Wash Speed | rpm | 34 | 34 | 34 | 34 | 34 | ||
甩干转速Extract Speed | rpm | 600 | 600 | 600 | 600 | 600 | ||
底箱Tank Volume | 1箱 Tank1 | L | 136 | 170 | 170 | 170 | 200 | |
2箱 Tank2 | L | 136 | 170 | 170 | 170 | 200 | ||
过滤器Filter Area | 单组纸芯过滤器 | |||||||
c机器电机总功率Power Motor | KW | 4 | 4 | 4.5 | 4.5 | 6 | ||
蒸汽耗量()Steam Consumption | kg/hr | 5-8 | 5-8 | 5-8 | 5-8 | 5-8 | ||
耗水量()Water Consumption | kg/hr | 250 | 250 | 250 | 250 | 250 | ||
机器尺寸 Dimensions |
Height | mm | 2040 | 2040 | 2040 | 2040 | 2040 | |
宽Length | mm | 1460 | 1690 | 1690 | 1690 | 1690 | ||
厚Width | mm | 1150 | 1150 | 1150 | 1250 | 1250 | ||
机器重量Net weight | Kg | 700 | 750 | 800 | 850 | 850 | ||
备注:S:蒸汽式:Q:蒸汽压力:4-6Kg/cm2冷却水压力:1.5-2 Kg/cm2;电源需求:380V/3PH/50HZ。 Remark: S: Steam heated;Steam pressure: 4-6Kg/cm2;Water pressure: 1.5-2 Kg/cm2; oltage: 380V/3PH/50HZ. |
