功能点Feature and functions
●本公司新研制的GL系列隔离式洗衣脱水机,能严格的无菌、无尘、防静电洗涤要求。通过隔离式洗衣机和隔离墙将洗衣机和隔离墙将洗衣房分成“洁净区”和“操作区”两个立的操作区间。洗涤物由位于“操作区”一侧的装料门装入,洗涤完毕后从位于“洁净区”一侧的卸料门取出,加上洁净空气控制系统的作用,可防止细菌和尘埃颗粒从“操作区”流向“洁净区”,从而避免洁净物的二次污染和交叉感染。
●GL系列隔离式洗衣机技术进、结构合理、运行经济、维护方便、性能良,广泛用于、食品、生物制药、核电站等环境有严格无尘、无菌要求的洗衣房,是洗衣服的理想洗涤设备。
●Our company newly developed GL-series isolated-type washers, which are able to meet strict sterile, dust-free, antstatic cleaning requirements. Laundry is divided into “clean zone ”and“operating area”of two separate operating ranges through isolated-type washer and isolation wall. Launderettes will be loaded into the washing machine through the loading door from the“operating area”. When washing is completed, wunder will be carried out form the“clean zone ”. With clean air control system, It will prevent bacteria and dust particles from the“operating area”to“clean zone”, this avoiding secondary pollution of clean washing and cross-infection.
●The company produces GL-series isolated-type washers, with advanced technology, reasonable structure, economic operation, convenient maintenance and excellent performance, are widely used in hospitals, food, biopharmaceutical, nuclear power plants where extremely strict dust and bacteri -afree environment sure being observed.
●本公司新研制的GL系列隔离式洗衣脱水机,能严格的无菌、无尘、防静电洗涤要求。通过隔离式洗衣机和隔离墙将洗衣机和隔离墙将洗衣房分成“洁净区”和“操作区”两个立的操作区间。洗涤物由位于“操作区”一侧的装料门装入,洗涤完毕后从位于“洁净区”一侧的卸料门取出,加上洁净空气控制系统的作用,可防止细菌和尘埃颗粒从“操作区”流向“洁净区”,从而避免洁净物的二次污染和交叉感染。
●GL系列隔离式洗衣机技术进、结构合理、运行经济、维护方便、性能良,广泛用于、食品、生物制药、核电站等环境有严格无尘、无菌要求的洗衣房,是洗衣服的理想洗涤设备。
●Our company newly developed GL-series isolated-type washers, which are able to meet strict sterile, dust-free, antstatic cleaning requirements. Laundry is divided into “clean zone ”and“operating area”of two separate operating ranges through isolated-type washer and isolation wall. Launderettes will be loaded into the washing machine through the loading door from the“operating area”. When washing is completed, wunder will be carried out form the“clean zone ”. With clean air control system, It will prevent bacteria and dust particles from the“operating area”to“clean zone”, this avoiding secondary pollution of clean washing and cross-infection.
●The company produces GL-series isolated-type washers, with advanced technology, reasonable structure, economic operation, convenient maintenance and excellent performance, are widely used in hospitals, food, biopharmaceutical, nuclear power plants where extremely strict dust and bacteri -afree environment sure being observed.
技术参数Technical parameters
型号 model 项目 item |
单位/unit | GL30 | GL50 | GL70 | GL100 | |
额定洗涤量 | max capacity | kg | 30 | 50 | 70 | 100 |
外形尺寸 | appearance size | |||||
height | mm | 1820 | 1820 | 1980 | 2050 | |
宽 | width | mm | 1320 | 1720 | 1520 | 1720 |
深 | depth | mm | 1100 | 1100 | 1500 | 1550 |
滚筒转速洗涤,均匀,中脱,脱转速根据需要由变频器设定 。 Drum rotation(r/min) washing even spread medium dewatering. Fast rotation limit set by vfd. |
||||||
电机功率 | electric power | KW | 4 | 5.5 | 7.5 | 7.5 |
接口尺寸 | interfaced | |||||
冷水进水口 | cold water inlet | inch | 1'' | 1'' | 1'' | 1'' |
热水进水口 | hot water inlet | inch | 1'' | 1'' | 1'' | 1'' |
蒸汽接口 | steam interface | inch | 1/2'' | 3/4'' | 1'' | 1'' |
排水口 | drain | inch | 3'' | 3'' | 4'' | 4'' |
重量 | weight | kg | 1110 | 1340 | 1920 | 3200 |
