2中小型洗脱机

2中小型洗脱机

●三层不锈钢结构,内胆、外筒、面板均采用耐酸碱、抗腐蚀的强度304不锈钢制造;内胆采用2.5mm厚度的304质不锈钢材料焊接而成,机身四面外壳采用304不锈钢装饰板制作。
●口径不锈钢装载门,配备安门锁,美观耐用、安可靠。
洗涤设备
 功能点Feature and functions
●三层不锈钢结构,内胆、外筒、面板均采用耐酸碱、抗腐蚀的强度304不锈钢制造;内胆采用2.5mm厚度的304质不锈钢材料焊接而成,机身四面外壳采用304不锈钢装饰板制作。
●口径不锈钢装载门,配备安门锁,美观耐用、安可靠。
●主轴轴承采用日本NSK、NTN或意利CCVI等其名产品。
●采用变频调速控制,节省电力,降噪音,运转加平稳可靠。
●压电器采用的名电气元器件,使用可靠,稳定性好。
●采用性能可靠的中文液晶电脑自动控制器,美观方,操作简单。

●Three layers stainless steel structure, inner, outer tube, panel adopts acid and alkali resistance, corrosion of high strength 304 stainless steel manufacturing; A 2.5 mm thickness of the tank 304 high quality stainless steel welded together, the fuselage shell adopts 304 stainless steel decorative materials production in all directions.
●Large stainless steel loading door, equipped with safe door latch, beautiful and durable, safe and reliable.
●The bearing of key parts are all world famous products, such as Japanese NSK、NTN or Italian CCVI.
●Frequency control, electricity saving and noise decreasing, reliable and stable.
●The low-voltage apparatus are all top grade electric components with high quality, reliable and stable.
●Full automatic control by computer board in Chinese, reliable and beautiful, easy to operate.


技术参数Technical parameters


    型号 model



项目 item
单位/unit QXSQ-1000 QXSQ-1200 QXSQ-1500 QXSQ-2000 QXSQ-2500
容量 Capacity kg 10 12 15 20 25
滚筒直径 Drum Diameter mm 580 580 660 760 800
滚筒深度 Drum Diameter mm 380 460 436 460 500
洗涤转速 Washing speed r/min 40 40 40 40 40
洗涤驱动电机功率 Motor KW 1.1 1.1 1.1 2.2 3
洗涤加热器功率 Heating KW 6 6 6 9 12
装机容量(蒸汽) Inst. Power(Steam kg 1.1 1.1 1.1 3 3
进水径 Water Inlet inch 1” 1” 1” 1” 1”
排水径 Water outlet inch 2” 2” 2” 2” 2”
Width mm 820 890 960 1050 1140
Depth mm 880 880 880 1070 1220
Height mm 1100 1100 1150 1360 1460
机器净重 Net Weight kg 460 480 520 580 680
