功能点Feature and functions
●YTP电热烫平机采用电加热,传动采用调速调整,根据加热温度和织物厚度随意调节速度。
●辊筒采用传质不锈钢制造,表面经磨削加工处理使织物磨损降到。
●运行可靠,采用减速器联接皮带轮及链轮传动,并配置传动引擎机构,运行平稳。
●副辊采用喷锌处理,抗腐蚀能力强,经久耐用。
●YTP the electric heating irons out machine uses thetric heating, the transmission uses the velocity modulation adjustment, according to heating temperature and fabric thickness at will adjustable speed.
●The big bowl uses the mass transfer stainless steel manufacture, the surface causes fabric attrition after abrasive machining processing to reduce lowly.
●The movement is reliable, uses the reduction gear joint belt pulley and the sprocket feed, and disposes the transmission engine organization, the guarantee movement is steady.
●All vice rollers use spurt zinc processing, corrosion resistance ability, durable.
●YTP电热烫平机采用电加热,传动采用调速调整,根据加热温度和织物厚度随意调节速度。
●辊筒采用传质不锈钢制造,表面经磨削加工处理使织物磨损降到。
●运行可靠,采用减速器联接皮带轮及链轮传动,并配置传动引擎机构,运行平稳。
●副辊采用喷锌处理,抗腐蚀能力强,经久耐用。
●YTP the electric heating irons out machine uses thetric heating, the transmission uses the velocity modulation adjustment, according to heating temperature and fabric thickness at will adjustable speed.
●The big bowl uses the mass transfer stainless steel manufacture, the surface causes fabric attrition after abrasive machining processing to reduce lowly.
●The movement is reliable, uses the reduction gear joint belt pulley and the sprocket feed, and disposes the transmission engine organization, the guarantee movement is steady.
●All vice rollers use spurt zinc processing, corrosion resistance ability, durable.
技术参数Technical parameters
型号 model 项目 item |
YTP-1800 | YTP-2200 | YTP-2500 | YTP-2800 | YTP-3000 | |
熨平宽度(mm) | Biggest ironing width | 1800 | 2200 | 2500 | 2800 | 3000 |
熨平速度(speed/min) | Ironing | 0-6 | 0-6 | 0-6 | 0-6 | 0-6 |
加热功率(KW) | Heated power | 27 | 32.4 | 36 | 43.2 | 43.2 |
加热温度(℃) | Highest heating temperature | 230 | 230 | 230 | 230 | 230 |
电机功率(KW) | Motor power | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
额定电压(V) | Rated voltage | 380 | 380 | 380 | 380 | 380 |
外形(长×宽×) (mm) |
Dimension (L×W×H) |
3000× 1250× 1250 |
3400× 1250× 1250 |
3700× 1250× 1250 |
4000× 1250× 1250 |
4200× 1250× 1250 |
整机重量(kg) | Machine weight | 1200 | 1300 | 1350 | 1400 | 1450 |
